CSB HR1232WF2 SLA (AGM) Battery

CSB HR1232WF2 SLA (AGM) Battery

SKU: CS-HR1232WF2 Categories: AGM-Lead Calcium, Brands, Chemistry, CSB, HR Series, HR1232W, Lead Acid Tags: AGM-Lead Calcium, CSB, HR Series, HR1232W, HR1232WF2, Lead Acid

As low as $30.82 each

CSB HR1232WF2 HR Series 12 Volt / 8.0 Ah @20 Hr with F2 (0.250″) Terminals and ABS Plastic Case

The BSI Pricing Advantage

price-discounts

Each (1 pieces) - $30.82 each

Add To Wishlist

Description

CSB HR1232WF2 HR Series 12 Volt / 8.0 Ah @20 Hr with F2 (0.250″) Terminals and ABS Plastic Case

Specifications
Battery Store SKU	CS-HR1232WF2
Dimensions	5.94″ (L) x 2.55″ (W) x 3.71″ (H)
Dimensions (mm)	150 mm (L) x 64.8 mm (W) x 94.3 mm (H)
Weight	5.2 lbs (2.34 kgs)

Additional information

Weight	5.2 lbs
Manufacturer	CSB
price-discounts	Each (1 pieces)
Product Line
Product Series	HR Series
Model	HR1232W
Terminal	F2 (0.250")
Terminal Layout
Case Material	ABS Plastic
UPC Code
Manufacturers Model #	HR1232WF2
Manufacturers SKU
Deprecated Model #
Applications
Voltage	12
Capacity (Nominal)	8.0 Ah @20 Hr
Capacity @20 Hr	8
Capacity @10 Hr
Capacity @1 Hr
Capacity @15 Min	32 W @15 Min
CCA
PHCA
Reserve Capacity
Chemistry	Lead Acid
Technology	AGM-Lead Calcium
Design Life
Service Life
Shelf Life	6
Internal Resistance
Maximum Current
Cycles @ 80% Discharge
Standby Charge Voltage	13.5 to 13.8 VDC
Cycle Charge Voltage	14.4 to 15.0 VDC
Maximum Charge Current
Operating Temp Low (°F)	5
Operating Temp High (°F)	122
Storage Temp Low (°F)	5
Storage Temp High (°F)	104
Operating Temp Low (°C)	-15
Operating Temp High (°C)	50
Storage Temp Low (°C)	-15
Storage Temp High (°C)	40
Length (In)	5.94
Width (In)	2.55
Height - Case (In)	3.71
Height - Overall (In)	3.88
Length (mm)	150
Width (mm)	64.8
Height - Case (mm)	94.3
Height - Overall (mm)	98.6
Weight (lb)	5.2
Weight (kg)	2.34
BCI Group	M7 Size
Manufacturers Warranty
Transportation Notes
Certifications
Qty Per Box
Qty Per Pallet
