EnerSys DataSafe NPX-35-6 Lead Acid Battery

SKU: EN-NPX-35-6F1 Categories: Brands, Chemistry, DataSafe, EnerSys, Lead Acid, NPX Series, NPX-35-6 Tags: DataSafe, EnerSys, Lead Acid, NPX Series, NPX-35-6

EnerSys DataSafe NPX Series NPX-35-6 6 Volt / 8.0 Ah @20 Hr with F1 (0.187″) Terminals

The BSI Pricing Advantage

price-discounts

Each (1 pieces)

Add To Wishlist

Description

EnerSys DataSafe NPX Series NPX-35-6 6 Volt / 8.0 Ah @20 Hr with F1 (0.187″) Terminals

Specifications
Battery Store SKU	EN-NPX-35-6F1
Dimensions	5.94″ (L) x 1.3″ (W) x 3.94″ (H)
Dimensions (mm)	151 mm (L) x 33 mm (W) x 94 mm (H)
Weight	3.146 lbs (1.43 kgs)

Additional information

Weight	3.146 lbs
Manufacturer	EnerSys
price-discounts	Each (1 pieces)
Product Line	DataSafe
Product Series	NPX Series
Model	NPX-35-6
Terminal	F1 (0.187")
Terminal Layout
Case Material	ABS Plastic
UPC Code
Manufacturers Model #	NPX-35-6
Manufacturers SKU	NPX-35-6
Deprecated Model #
Applications
Voltage	6
Capacity (Nominal)	8.0 Ah @20 Hr
Capacity @20 Hr	8
Capacity @10 Hr
Capacity @1 Hr
Capacity @15 Min	35 W @15 Min
CCA
PHCA
Reserve Capacity
Chemistry	Lead Acid
Technology
Design Life
Service Life	3-5 Years
Shelf Life
Internal Resistance	6
Maximum Current
Cycles @ 80% Discharge
Standby Charge Voltage
Cycle Charge Voltage	13.5 to 13.8 Volts
Maximum Charge Current	14.4 to 15.0 Volts
Operating Temp Low (°F)
Operating Temp High (°F)
Storage Temp Low (°F)	-5°F (-15°C) to 122°F (50°C)
Storage Temp High (°F)
Operating Temp Low (°C)
Operating Temp High (°C)
Storage Temp Low (°C)
Storage Temp High (°C)
Length (In)	5.94
Width (In)	1.3
Height - Case (In)	3.94
Height - Overall (In)	3.9
Length (mm)	151
Width (mm)	33
Height - Case (mm)	94
Height - Overall (mm)	99
Weight (lb)	3.146
Weight (kg)	1.43
BCI Group
Manufacturers Warranty	12 Months
Transportation Notes
Certifications
Qty Per Box
Qty Per Pallet
uncategorized
