GS Yuasa NPX-35FR SLA (AGM) Battery

Description

GS Yuasa NPX Series NPX-35FR 12 Volt / 8.5 Ah @20 Hr with F1 (0.187″) Terminals

Specifications
Battery Store SKU	GS-NPX-35F1FR
Dimensions	5.94″ (L) x 2.56″ (W) x 3.62″ (H)
Dimensions (mm)	151 mm (L) x 65 mm (W) x 92 mm (H)
Weight	5.8 lbs (2.65 kgs)

Additional information

Weight	5.8 lbs
Manufacturer	GS Yuasa
price-discounts	Each (1 Pieces), Box/Case (10 Pieces), Pallet Layer (90 Pieces), Pallet (360 Pieces)
Product Line
Product Series	NPX Series
Model	NPX-35
Terminal	F1 (0.187")
Terminal Layout
Case Material	Flame Retardant UL94-V0
UPC Code
Manufacturers Model #	NPX-35FR
Manufacturers SKU	NPX-35FR
Deprecated Model #
Applications
Voltage	12
Capacity (Nominal)	35 W @ 15 min
Capacity @20 Hr	8.5 Ah @20 Hr
Capacity @10 Hr
Capacity @1 Hr
Capacity @15 Min
CCA
PHCA
Reserve Capacity
Chemistry	Lead Acid
Technology	AGM-Lead Calcium
Design Life
Service Life	3-5 Years
Shelf Life	6 Months
Internal Resistance
Maximum Current
Cycles @ 80% Discharge
Standby Charge Voltage	13.5 to 13.8 Volts
Cycle Charge Voltage	14.4 to 15.0 Volts
Maximum Charge Current
Operating Temp Low (°F)	-5
Operating Temp High (°F)	122
Storage Temp Low (°F)
Storage Temp High (°F)
Operating Temp Low (°C)	-15
Operating Temp High (°C)	50
Storage Temp Low (°C)
Storage Temp High (°C)
Length (In)	5.94
Width (In)	2.56
Height - Case (In)	3.62
Height - Overall (In)	3.84
Length (mm)	151
Width (mm)	65
Height - Case (mm)	92
Height - Overall (mm)	8
Weight (lb)	5.8
Weight (kg)	2.65
BCI Group
Manufacturers Warranty	24 Months
Transportation Notes
Certifications
Qty Per Box
Qty Per Pallet
