PowerSonic DCG12-110 Lead Acid Battery

PowerSonic DCG Series DCG12-110 12 Volt / 110 Ah @20 Hr Lead Acid Battery with Recessed M6 Terminals / ABS Plastic Case

Loading...

Description

PowerSonic DCG Series DCG12-110 12 Volt / 110 Ah @20 Hr Lead Acid Battery with Recessed M6 Terminals / ABS Plastic Case

Specifications
Battery Store SKU PS-DCG12-110R
Dimensions 16.14″ (L) x 6.97″ (W) x 8.86″ (H)
Dimensions (mm) 410 mm (L) x 177 mm (W) x 225 mm (H)
Weight 79.244 lbs (36.02 kgs)

Product Notes

Superior cyclic life to AGM technology

Additional information

Weight 79.244 lbs
Manufacturer

PowerSonic

price-discounts

Pallet Layer (10 pieces), Pallet (20 pieces)

Product Line
Product Series

DCG Series

Model

DCG12-110

Terminal

Recessed M6

Terminal Layout
Case Material

ABS Plastic

UPC Code
Manufacturers Model #

DCG12-110

Manufacturers SKU
Deprecated Model #
Applications
Voltage

12

Capacity (Nominal)

110 Ah @20 Hr

Capacity @20 Hr

110

Capacity @10 Hr

102.3

Capacity @1 Hr

60.5

Capacity @15 Min
CCA
PHCA
Reserve Capacity
Chemistry

Lead Acid

Technology

Gel

Design Life
Service Life
Shelf Life

12

Internal Resistance

5.1 mOhm

Maximum Current
Cycles @ 80% Discharge

600

Standby Charge Voltage

13.5 to 13.8 VDC

Cycle Charge Voltage

14.1 to 14.7 VDC

Maximum Charge Current

0.25C

Operating Temp Low (°F)

-4

Operating Temp High (°F)

140

Storage Temp Low (°F)

5

Storage Temp High (°F)

122

Operating Temp Low (°C)

-20

Operating Temp High (°C)

60

Storage Temp Low (°C)

-15

Storage Temp High (°C)

50

Length (In)

16.14

Width (In)

6.97

Height - Case (In)

8.86

Height - Overall (In)

8.86

Length (mm)

410

Width (mm)

177

Height - Case (mm)

225

Height - Overall (mm)

225

Weight (lb)

79.244

Weight (kg)

36.02

BCI Group
Manufacturers Warranty
Transportation Notes
Certifications
Qty Per Box
Qty Per Pallet
