PowerSonic PGFT-12V55 Lead Acid Battery
As low as $128.34 each
PowerSonic PG FT Series PGFT-12V55 12 Volt / 57.1 Ah @10 Hr Lead Acid Battery with Recessed M8 Terminals / ABS Plastic Case
Loading...
Description
PowerSonic PG FT Series PGFT-12V55 12 Volt / 57.1 Ah @10 Hr Lead Acid Battery with Recessed M8 Terminals / ABS Plastic Case
| Specifications | |
|---|---|
| Battery Store SKU | PS-PGFT-12V55R |
| Dimensions | 10.91″ (L) x 4.17″ (W) x 8.74″ (H) |
| Dimensions (mm) | 277 mm (L) x 106 mm (W) x 222 mm (H) |
| Weight | 39.622 lbs (18.01 kgs) |
Additional information
| Weight | 39.622 lbs |
|---|---|
| Manufacturer | PowerSonic |
| price-discounts | Each (1 pieces), Box/Case (1 pieces), Pallet Layer (16 pieces), Pallet (32 pieces) |
| Product Line | |
| Product Series | PG FT Series |
| Model | PGFT-12V55 |
| Terminal | Recessed M8 |
| Terminal Layout | |
| Case Material | ABS Plastic |
| UPC Code | |
| Manufacturers Model # | PGFT-12V55 |
| Manufacturers SKU | |
| Deprecated Model # | |
| Applications | |
| Voltage | 12 |
| Capacity (Nominal) | 57.1 Ah @10 Hr |
| Capacity @20 Hr | 60.6 |
| Capacity @10 Hr | 57.1 |
| Capacity @1 Hr | 38.1 |
| Capacity @15 Min | |
| CCA | |
| PHCA | |
| Reserve Capacity | |
| Chemistry | Lead Acid |
| Technology | VRLA-AGM |
| Design Life | 12 Years |
| Service Life | Up to 6 Years |
| Shelf Life | 6 |
| Internal Resistance | 6.0 mOhm |
| Maximum Current | 600 |
| Cycles @ 80% Discharge | |
| Standby Charge Voltage | 13.5 to 13.8 VDC |
| Cycle Charge Voltage | 14.1 to 14.7 VDC |
| Maximum Charge Current | 0.25C |
| Operating Temp Low (°F) | -4 |
| Operating Temp High (°F) | 140 |
| Storage Temp Low (°F) | 5 |
| Storage Temp High (°F) | 122 |
| Operating Temp Low (°C) | -20 |
| Operating Temp High (°C) | 60 |
| Storage Temp Low (°C) | -15 |
| Storage Temp High (°C) | 50 |
| Length (In) | 10.91 |
| Width (In) | 4.17 |
| Height - Case (In) | 8.74 |
| Height - Overall (In) | 8.74 |
| Length (mm) | 277 |
| Width (mm) | 106 |
| Height - Case (mm) | 222 |
| Height - Overall (mm) | 222 |
| Weight (lb) | 39.622 |
| Weight (kg) | 18.01 |
| BCI Group | |
| Manufacturers Warranty | |
| Transportation Notes | |
| Certifications | |
| Qty Per Box | |
| Qty Per Pallet |
