Universal Power UB121000 Lead Acid Battery
$357.56
Universal Power UB121000 UB Series 12 Volt / 100 Ah @20 Hr Lead Acid Battery with Nut & Bolt Terminals
Out of stock
Description
Universal Power UB121000 UB Series 12 Volt / 100 Ah @20 Hr Lead Acid Battery with Nut & Bolt Terminals
| Specifications | |
|---|---|
| Battery Store SKU | UB-121000NB |
| Dimensions | 12.17″ (L) x 6.61″ (W) x 9.16″ (H) |
| Dimensions (mm) | 309.11 mm (L) x 167.89 mm (W) x 232.66 mm (H) |
| Weight | 63.93 lbs (29.1 kgs) |
Additional information
| Weight | 28.998457770117 lbs |
|---|---|
| Manufacturer | Universal Power |
| Product Line | |
| Product Series | UB Series |
| Model | UB-121000 |
| Terminal | Nut & Bolt |
| Terminal Layout | |
| Case Material | ABS Plastic |
| UPC Code | |
| Manufacturers Model # | UB121000 |
| Manufacturers SKU | 45978 |
| Deprecated Model # | |
| Applications | |
| Voltage | 12 |
| Capacity (Nominal) | 100 Ah @20 Hr |
| Capacity @20 Hr | 100 |
| Capacity @10 Hr | |
| Capacity @1 Hr | |
| Capacity @15 Min | |
| CCA | |
| PHCA | |
| Reserve Capacity | |
| Chemistry | Lead Acid |
| Technology | AGM-Lead Calcium |
| Design Life | 5 Years |
| Service Life | 3 to 5 Years |
| Shelf Life | 6 |
| Internal Resistance | |
| Maximum Current | |
| Cycles @ 80% Discharge | 350 |
| Standby Charge Voltage | 13.6 – 13.8 Volts |
| Cycle Charge Voltage | 14.6 – 14.8 Volts |
| Maximum Charge Current | C/3 |
| Operating Temp Low (°F) | 32 |
| Operating Temp High (°F) | 104 |
| Storage Temp Low (°F) | 5 |
| Storage Temp High (°F) | 104 |
| Operating Temp Low (°C) | 0 |
| Operating Temp High (°C) | 40 |
| Storage Temp Low (°C) | -15 |
| Storage Temp High (°C) | 40 |
| Length (In) | 12.17 |
| Width (In) | 6.61 |
| Height - Case (In) | 9.16 |
| Height - Overall (In) | 9.16 |
| Length (mm) | 309.11 |
| Width (mm) | 167.89 |
| Height - Case (mm) | 232.66 |
| Height - Overall (mm) | 232.66 |
| Weight (lb) | 63.93 |
| Weight (kg) | 29.1 |
| BCI Group | Group 27 |
| Manufacturers Warranty | 12 Months |
| Transportation Notes | |
| Certifications | |
| Qty Per Box | 1 |
| Qty Per Pallet | 52 |
Similar Products from this Brand
Form, Fit and Function Equivalents
Please choose search option from the menu to start your search...
Universal Power UB121000 Lead Acid Battery
Universal Power UB121000 UB Series 12 Volt / 100 Ah @20 Hr Lead Acid Battery with Recessed M6 Terminals
Out of stock
Description
Universal Power UB121000 UB Series 12 Volt / 100 Ah @20 Hr Lead Acid Battery with Recessed M6 Terminals
| Specifications | |
|---|---|
| Battery Store SKU | UB-121000R |
| Dimensions | 12.17″ (L) x 6.61″ (W) x 8.35″ (H) |
| Dimensions (mm) | 309.11 mm (L) x 167.89 mm (W) x 212.09 mm (H) |
| Weight | 63.93 lbs (29.1 kgs) |
Additional information
| Weight | 28.998457770117 lbs |
|---|---|
| Manufacturer | Universal Power |
| Product Line | |
| Product Series | UB Series |
| Model | UB-121000 |
| Terminal | Recessed M6 |
| Terminal Layout | |
| Case Material | ABS Plastic |
| UPC Code | |
| Manufacturers Model # | UB121000 |
| Manufacturers SKU | 45973 |
| Deprecated Model # | |
| Applications | |
| Voltage | 12 |
| Capacity (Nominal) | 100 Ah @20 Hr |
| Capacity @20 Hr | 100 |
| Capacity @10 Hr | |
| Capacity @1 Hr | |
| Capacity @15 Min | |
| CCA | |
| PHCA | |
| Reserve Capacity | |
| Chemistry | Lead Acid |
| Technology | AGM-Lead Calcium |
| Design Life | 5 Years |
| Service Life | 3 to 5 Years |
| Shelf Life | 6 |
| Internal Resistance | |
| Maximum Current | |
| Cycles @ 80% Discharge | 350 |
| Standby Charge Voltage | 13.6 – 13.8 Volts |
| Cycle Charge Voltage | 14.6 – 14.8 Volts |
| Maximum Charge Current | C/3 |
| Operating Temp Low (°F) | 32 |
| Operating Temp High (°F) | 104 |
| Storage Temp Low (°F) | 5 |
| Storage Temp High (°F) | 104 |
| Operating Temp Low (°C) | 0 |
| Operating Temp High (°C) | 40 |
| Storage Temp Low (°C) | -15 |
| Storage Temp High (°C) | 40 |
| Length (In) | 12.17 |
| Width (In) | 6.61 |
| Height - Case (In) | 8.35 |
| Height - Overall (In) | 8.35 |
| Length (mm) | 309.11 |
| Width (mm) | 167.89 |
| Height - Case (mm) | 212.09 |
| Height - Overall (mm) | 212.09 |
| Weight (lb) | 63.93 |
| Weight (kg) | 29.1 |
| BCI Group | Group 27 |
| Manufacturers Warranty | 12 Months |
| Transportation Notes | |
| Certifications | |
| Qty Per Box | 1 |
| Qty Per Pallet | 52 |
