Universal Power UB12150 Lead Acid Battery

SKU: UB-12150F3 Categories: AGM-Lead Calcium, Brands, Chemistry, Lead Acid, UB Series, UB-12150, Universal Power Tags: 40658, AGM-Lead Calcium, Lead Acid, UB Series, UB-12150, UB12150, Universal Power

$64.42

Universal Power UB12150 UB Series 12 Volt / 15 Ah @20 Hr Lead Acid Battery with Tab (0.31”) Terminals

The BSI Pricing Advantage

Out of stock

Description

Universal Power UB12150 UB Series 12 Volt / 15 Ah @20 Hr Lead Acid Battery with Tab (0.31”) Terminals

Specifications
Battery Store SKU	UB-12150F3
Dimensions	5.94″ (L) x 3.89″ (W) x 3.94″ (H)
Dimensions (mm)	151.1 mm (L) x 98.8 mm (W) x 100 mm (H)
Weight	8.5 lbs (3.9 kgs)

Additional information

Weight	3.8555747074299 lbs
Manufacturer	Universal Power
Product Line
Product Series	UB Series
Model	UB-12150
Terminal	Tab (0.31”)
Terminal Layout
Case Material	ABS Plastic
UPC Code
Manufacturers Model #	UB12150
Manufacturers SKU	40658
Deprecated Model #
Applications
Voltage	12
Capacity (Nominal)	15 Ah @20 Hr
Capacity @20 Hr	15
Capacity @10 Hr
Capacity @1 Hr
Capacity @15 Min
CCA
PHCA
Reserve Capacity
Chemistry	Lead Acid
Technology	AGM-Lead Calcium
Design Life	5 Years
Service Life	3 to 5 Years
Shelf Life	6
Internal Resistance
Maximum Current
Cycles @ 80% Discharge	350
Standby Charge Voltage	13.6 – 13.8 Volts
Cycle Charge Voltage	14.6 – 14.8 Volts
Maximum Charge Current	C/3
Operating Temp Low (°F)	32
Operating Temp High (°F)	104
Storage Temp Low (°F)	5
Storage Temp High (°F)	104
Operating Temp Low (°C)	0
Operating Temp High (°C)	40
Storage Temp Low (°C)	-15
Storage Temp High (°C)	40
Length (In)	5.94
Width (In)	3.89
Height - Case (In)	3.94
Height - Overall (In)	3.94
Length (mm)	151.1
Width (mm)	98.8
Height - Case (mm)	100
Height - Overall (mm)	100
Weight (lb)	8.5
Weight (kg)	3.9
BCI Group
Manufacturers Warranty	12 Months
Transportation Notes
Certifications
Qty Per Box	4
Qty Per Pallet	336

Form, Fit and Function Equivalents
