Universal Power UB1250FR Lead Acid Battery

Universal Power UB1250FR UB Series 12 Volt / 5 Ah @20 Hr Lead Acid Battery with F2 (0.250″) Terminals

Out of stock

Loading...

Description

Universal Power UB1250FR UB Series 12 Volt / 5 Ah @20 Hr Lead Acid Battery with F2 (0.250″) Terminals

Specifications
Battery Store SKU UB-1250F2FR
Dimensions 3.54″ (L) x 2.76″ (W) x 4.21″ (H)
Dimensions (mm) 89.916 mm (L) x 70.104 mm (W) x 106.93 mm (H)
Weight 3.09 lbs (1.4 kgs)

Additional information

Weight 1.4016148054069 lbs
Manufacturer

Universal Power

Product Line
Product Series

UB Series

Model

UB-1250

Terminal

F2 (0.250")

Terminal Layout
Case Material

Flame Retardant ABS Plastic

UPC Code
Manufacturers Model #

UB1250FR

Manufacturers SKU

45565

Deprecated Model #
Applications
Voltage

12

Capacity (Nominal)

5 Ah @20 Hr

Capacity @20 Hr

5

Capacity @10 Hr
Capacity @1 Hr
Capacity @15 Min
CCA
PHCA
Reserve Capacity
Chemistry

Lead Acid

Technology

AGM-Lead Calcium

Design Life

5 Years

Service Life

3 to 5 Years

Shelf Life

6

Internal Resistance
Maximum Current
Cycles @ 80% Discharge

350

Standby Charge Voltage

13.6 – 13.8 Volts

Cycle Charge Voltage

14.6 – 14.8 Volts

Maximum Charge Current

C/3

Operating Temp Low (°F)

32

Operating Temp High (°F)

104

Storage Temp Low (°F)

5

Storage Temp High (°F)

104

Operating Temp Low (°C)

0

Operating Temp High (°C)

40

Storage Temp Low (°C)

-15

Storage Temp High (°C)

40

Length (In)

3.54

Width (In)

2.76

Height - Case (In)

4.21

Height - Overall (In)

4.21

Length (mm)

89.916

Width (mm)

70.104

Height - Case (mm)

106.93

Height - Overall (mm)

106.93

Weight (lb)

3.09

Weight (kg)

1.4

BCI Group
Manufacturers Warranty

12 Months

Transportation Notes
Certifications
Qty Per Box

10

Qty Per Pallet

850
